The XT150 silicone wire harness is a type of connecting wire harness with silicone as the insulating layer, typically designed for high-current transmission scenarios. The insulator is made of silicone, which features flame-retardant properties and can ensure operational safety to a certain extent. Mostly circular or strip-shaped in appearance, it usually comes with AC/DC connectors and is suitable for connection of various electrical devices.
The XT150 silicone wire harness is a connecting cable designed for use with the XT150 high-current plug. Its conductors are made of tinned copper cores, and the insulation is made of silicone material. It is commonly available in 10/12 AWG sizes, with a temperature resistance range of approximately -60°C to 180°C. It features high-current transmission, flexibility for easy wiring, aging resistance, and resistance to moisture and chemical corrosion. The cable length can be customized and is plug-and-play. It is suitable for power connections between batteries and ESCs, motors, or controllers in applications such as RC models/drones, energy storage devices, electric vehicles, and balance bikes.
The XT150 silicone wiring harness is a type of connector cable that uses silicone material as the insulation layer and is equipped with an XT150 plug, commonly used in high-current transmission scenarios. The wires in the harness are usually made of materials such as tinned copper, which offer good conductivity and corrosion resistance. The insulation layer made of silicone material features high and low-temperature resistance (generally usable in environments ranging from -60°C to 180°C), moisture resistance, chemical corrosion resistance, and excellent electrical insulation properties. It can be customized according to customer requirements, with no fixed standards, and common lengths include 0.6 meters, 1 meter, and 2 meters.
The XT150 high-current DC connector is built for high-power transmission. It’s widely used in power circuits of large RC aircraft and models, allowing easy frequent plugging, unplugging and battery swaps. Ideal for power battery systems of heavy-duty drones (agricultural, cargo types), it ensures stable performance in harsh environments. It also connects batteries, controllers and motors in low-speed EVs (scooters, AGV carts, forklifts), handling high-power charging/discharging cycles with ease. Additionally, it fits industrial setups (robot power, energy storage test platforms) and outdoor applications (RV power, emergency supplies, water propellers). With high-temperature resistance and superior insulation, the XT150 excels in diverse conditions.
|
Part name |
Material name and specifications |
|
Product Model |
XT150 |
|
Current |
60A/130A |
|
Rated voltage |
DC 500V |
|
Plating |
Gold Plated |
|
Plastic material |
PA66 |
|
Use time |
1000 times |
|
Fire rating |
UL94 V0 |
|
Temperature range |
-20℃to120℃ |
|
Wiring method |
welding |
|
Wire gauge |
8AWG |
|
Gender |
Male Female |
