SMT Single row

SMT Single Row connectors provide a reliable and compact solution for surface-mount applications, offering precise connectivity in various electronic designs. These headers are particularly suited for high-density PCB layouts, where space optimization is crucial. Key features include a 1.27 Pitch spacing that ensures stable signal transmission and compatibility with fine-pitch components. Additionally, the design minimizes the risk of dislocation during assembly or operation, enhancing durability. For mating options, the SMT Single Row can be paired with a female pin header to create secure interconnections, ideal for applications requiring repeated connections and disconnections. This versatility makes them a popular choice across industries such as automotive, telecommunications, and consumer electronics.


The SMT Single Row connector is engineered to meet rigorous performance standards, ensuring consistent operation in demanding environments. It features a robust construction that resists environmental stressors, including moisture, dust, and temperature fluctuations. With a focus on precision, the SMT Single Row offers exceptional electrical conductivity and mechanical stability, reducing the likelihood of signal loss or connection failure. Below are the detailed specifications presented in both list and table formats for clarity and professional reference.

  • Pitch: 1.27mm
  • Current Rating: 1.0A
  • Voltage Rating: 50V AC/DC
  • Contact Resistance: 20mΩ max
  • Insulation Resistance: 1000MΩ min
  • Operating Temperature: -40°C to +105°C
  • Material: High-temperature plastic housing, phosphor bronze contacts
  • Plating: Gold flash over nickel
Parameter Specification
Number of Positions 2 to 40 pins
Mounting Type Surface Mount (SMT)
Polarization Keyed for correct orientation
Mating Cycles Up to 500 cycles
Flammability Rating UL94V-0
